Lumision 40AMP 12V DC Water proof Relay and Harness 5-PIN SPDT Bosch Style 40A

Item Feature:

• Life Expectancy Electrical: 100,000 Operations (at 30 Operations/minute)

• Life Expectancy Mechanical: 10,000,000 Operations

• Temperature Range: -30 ~ +80 degrees Celsius

• Vibration Resistance: 10~55Hz, 1.5mm

• Shock Resistance: Operations Extremes: 10g. Damage Limits: 100g

• Humidity: 40% ~ 85%

• Insulation Resistance: 100m ohm minimum at 500V DC

• Dielectric Strength Between Open Contacts: 500V AC (for one minute/sec)

• Between Contact and coil: 750AC (for one minute/sec)

• Trigger Time: 7ms

• Release Time: 5ms
